UAV & Industrial Part References
Machined carbon fiber plates, frames and tube assemblies for UAV and industrial applications.
Give each component a drawing revision, mark critical interfaces and show wiring or maintenance clearance. Aviation qualification is a separate project requirement.
Carbon Fiber Quadcopter Frame Kit
无人机及工业零部件Frame-kit reference with arm and centre-plate geometry. Confirm the supplied component set and the system-specific design requirements before any operational use.
请注明图纸修订号、所需数量以及主要接口尺寸。.
Long Slotted Carbon Fiber Mounting Plate
无人机及工业零部件Elongated plate reference with a central opening and end features. Clarify whether the opening provides access, clearance or adjustment in the intended assembly.
请注明图纸修订号、所需数量以及主要接口尺寸。.
Machined Carbon Fiber Bracket Plates
无人机及工业零部件Profiled plate references for a bracket or frame assembly. The stacked view shows a component family and does not establish a specific supplied quantity.
请注明图纸修订号、所需数量以及主要接口尺寸。.
Paired Slotted Carbon Fiber Frame Plates
无人机及工业零部件Paired plate reference with slots and perimeter mounting features. Specify the geometry and quantity of each plate rather than assuming the pictured pair is a standard kit.
请注明图纸修订号、所需数量以及主要接口尺寸。.
Rectangular Carbon Fiber Mounting Plate
无人机及工业零部件Rectangular plate reference with slots and mounting holes. Provide the governing dimensions and mating hardware to define a finished part.
请注明图纸修订号、所需数量以及主要接口尺寸。.
Rounded Carbon Fiber Mounting Plate
无人机及工业零部件Rounded plate reference with several mounting apertures. Define the functional interfaces and the direction in which the part is installed.
请注明图纸修订号、所需数量以及主要接口尺寸。.
Three-Arm Carbon Fiber Mounting Plate
无人机及工业零部件Three-arm plate reference with mounting features. The outline is a starting point for a drawing review, not a statement of a universal payload rating.
请注明图纸修订号、所需数量以及主要接口尺寸。.
X-Profile Carbon Fiber Chassis Plate
无人机及工业零部件X-profile plate reference with multiple openings. Suitable as a starting point for discussing a custom machined chassis component against a project drawing.
请注明图纸修订号、所需数量以及主要接口尺寸。.
